A bit of ADO: The challenge of addressing overheating and noise?

Approved Document O (AD-O) of the UK Building regulations deals with overheating in domestic dwellings and residential properties. For example care homes and student accommodation.

Written by our Principle Acoustic Consultant Nick Swainston, Approved Document O- The Influence of Noise summaries how document O will affect the construction (Acoustic) industry. It also addresses how the environmental noise affecting new homes will have a significant impact on how they are designed to mitigate overheating.

Approved Document O – The Influence of Noise

Approved Document O (AD-O) of the UK building regulations deals with overheating in domestic dwellings and residential properties such as care homes and student accommodation. Statutory guidance on this new building regulation is laid out within the newly approved document and came into effect on 15 June 2022.


Noise constraints are an important factor when considering strategies to mitigate overheating. It’s simple to understand that large openings in the facade of a building to mitigate overheating conditions have the potential to increase internal ambient noise levels inside bedroom accommodation.


Developers can use one of two methods to show compliance with the document: The Simplified Method and the Dynamic Thermal Method. The simplified method seeks to limit glazed areas. AD-O sets out tables that establish a maximum amount of glazing and a minimum free area for ventilation in the external facade relative to the total floor area of the accommodation and the building’s overheating risk category.


Following the simplified method, the building’s overheating risk category is determined by its location in one of the following areas.

• ‘Moderate risk’ location – England, excluding high-risk parts of London
• ‘High risk’ location – urban and some suburban parts of London

Allowable façade open free areas are lower for high-risk locations. This is to mitigate the potential for noise issues in urban areas. It is expected that the simplified method will only be possible where the road traffic is not close to the building, and the number of vehicle movements at night is limited.


The Dynamic Thermal Model is expected to be the route to compliance followed by most developments. This is because the assessment provides more flexibility in how a building design can be developed to prevent overheating.


Sections 3.2 & 3.3 regarding noise in AD-O make it clear that the strategy used to prevent overheating must be usable. The documents set limits on the internal ambient noise levels in bedrooms to prevent nighttime sleep disturbance which is known to have a proven negative effect on the health and wellbeing of individuals.


The document confirms the expectations that windows are likely to be closed during sleeping hours if noise within bedrooms exceeds either of the following limits.

a. 4odB LAeq,T, averaged over 8 hours (between 11pm and 7am).
b. ssdB LAFmax, more than 10 times a night (between 11 pm and 7 am).

The Dynamic Thermal Model in urban areas needs to take into account the likelihood that windows will be closed during sleeping hours (11 pm to 7 am). Restricted window openings are an approach that could be considered. However the associated reduction in the equivalent open area must be accounted for in the overheating assessment.


The façade design of the domestic dwellings and residential buildings is likely to be impacted by the overheating strategy. It is, therefore, necessary to understand risks and solutions associated with noise early in the design process, certainly well before any planning application is made.


The regulations require the exploration of all passive means (inc. using mechanical ventilation to remove heat) before opting for air conditioning. The following hierarchical approach to removing excess heat is recommended in the regulation:

  1. Opening windows
  2. Ventilation louvres in external walls
  3. A mechanical ventilation system
  4. A mechanical cooling system

Appointing an acoustic specialist to complete a risk assessment at an early stage in the design will be fundamental to informing the building design. The work required will help to define what overheating strategy is possible. It will importantly feed into the cost of construction and land viability.

Summary

The design philosophy set out in approved document O is clear. The solutions proposed must control overheating and be usable. Internal ambient and maximum noise levels must be controlled to acceptable levels that will not affect the health and wellbeing of the building occupants.


CDC can help by providing an early-stage risk assessment relating to noise at the proposed development site. This will aid the design process and lead to a developed solution before committing the façade of the building to planning.
